ICC’s wall-mount fiber optic enclosure is designed to provide a compact distribution point to feed a high capacity of optic cables to zones. The enclosure has a convenient drop-down door with latches positioned on both sides. Reusable cable ties are included to secure the door, a padlock is optional. The door also comes with a wiring label for system administration. The enclosure can be mounted onto walls in remote indoor locations. Up to two LGX® compatible products can be installed, such as adapter panels and MPO cassettes. The enclosure can support patching for up to 48 LC, 24 SC or 12 ST fiber optic connections. Rubber grommets are placed at the cable entry and exit points on the top and bottom of the enclosure to protect cables. ICC’s wall mount enclosure is made with 18 gauge steel, black power-coated, and meets and exceeds all TIA-568-C.3 requirements. This enclosure provides a safe and clean environment for fiber optics.
Features
- Compact size; 13″ width x 6.5″ height x 3.5″ depth
- Designed to be wall-mounted
- Folded-edge frame for improved strength
- Built-in cable management spools
- LGX® compatible
- Holds two Classic adapter panels or MPO cassettes
- Holds three splice trays
Specifications
Material:
Enclosure: 18 Gauge CRS
Adapter Bulkhead: 16 Gauge CRS
Finish: Black Powder Coating
