Description
Features
- Constructed of 14 and 16 gauge steel.
- Includes front plastic pull handle locking mechanism.
- The inside drawer width is 16.12" wide.
- Complete drawer with slides, hardware, lock & two keys.
- Available in 3 depths.
- Rear support brackets are included for all depths or can be supported from the rear rack rail.
- 6-Pack of 10-32 rack screws are included.
- Finished in textured RAL9005 black or RAL 7035 light gray powder coat. Complies with the Greenguard guidelines for indoor air quality.
- Up to 145 lbs (66 kg) load rating when mounted to two-pair/4-post rack rails.
- Rated for 60 lbs (27 kg) when mounted one-pair/2-post rack rails.
- TAA-compliant for federal GSA schedule purchases within the USA.
- RoHS and REACH compliant.
- Manufactured in North America.
Accessories
-
Hardware for Rack Mounting Solutions
-
Wing Knob Latch
-
Rack Equipment Installation Tool
Attributes
| Additional Downloads |
|---|
| Specification Sheet |
| Part Attributes | |
|---|---|
| Part Number | RDRW1900316BK1 |
| Series | Rack Mount Locking Storage Drawer (RDRW Series) |
| Short Description | 2U 16D LOCKING DRAWER |
| Shipping Weight | 22 lbs (9.98 kg) |
| UNSPSC | 43201618 |
| UPC | 623980481456 |
| REACH Compliant | Yes (more info...) |
| RoHS Compliant | Yes (more info...) |
