Description
Features
- Constructed in 16-gauge steel.
- Prevents cables from sagging when running front to rear.
- Universal design compatible with both racks and cabinets.
- Cable pass-through holes are evenly spaced.
- Easily mounts to EIA mounting rails.
- Cable tie-off slots help keep cables managed.
- Requires two pairs of mounting rails to install.
- Requires mounting hardware.
- Finished in textured RAL9005 black powder paint finish.
- TAA-compliant for federal GSA schedule purchases within the USA.
- RoHS Compliant.
- Manufactured in North America.
Accessories
-
Hardware for Rack Mounting Solutions
-
Hook and Loop Convenience Roll
-
Rack Equipment Installation Tool
Part Details
Click Part No, below, for details (e.g., Product drawings, assembly instructions, ship weight)
Units shown: inch. Switch units to: mm
| Part No. | Overall Dimensions | Rack | |||
|---|---|---|---|---|---|
| Height | Width | Min Depth | Max Depth | Units | |
| RDCM2136BK | 3.00 | 3.95 | 21.50 | 36.50 | 2U |
| RDCM3348BK | 3.00 | 3.95 | 33.50 | 48.50 | 2U |
Attributes
| Additional Downloads |
|---|
| Specification Sheet |
| BUL86724 - RACK DEPTH CABLE MNGR INSTR. |
| Part Attributes | |
|---|---|
| Part Number | RDCM2136BK |
| Series | Adjustable Depth Front-To-Rear Cable Manager (RDCM Series) |
| Short Description | 2U 21-36D ADJ DEPTH CABLE MGR |
| Shipping Weight | 4.55 lbs (2.06 kg) |
| UNSPSC | 43223305 |
| UPC | 623980187341 |
| REACH Compliant | Yes (more info...) |
| RoHS Compliant | Yes (more info...) |
