Description
Features
- Constructed of heavy-duty 12-gauge steel.
- Formed for added strength.
- Fits standard EIA-compliant rails.
- The MIS-D mounting pattern is part of the Video Electronics Standards Association (VESA), Mounting Interface Standard (MIS). Specifically, MIS-D is commonly associated with:
- VESA 75 x 75 mm or 100 x 100 mm mounting hole patterns.
- Typically used for monitors that are up to 30 inches.
- Maximum recommended weight capacity is 30.8 lbs (14 kg) according to the VESA standard.
- Includes hardware for use in the back of your screen or monitor.
- Finished in textured RAL9005 black powder coat. Complies with the Greenguard guidelines for indoor air quality.
- TAA-compliant for federal GSA schedule purchases within the USA.
- RoHS and REACH compliant.
- Manufactured in North America within an ISO 9001:2015 certified facility.
Accessories
-
Hardware for Rack Mounting Solutions
-
Rack Rail Reducer Panel
Part Details
Click Part No, below, for details (e.g., Product drawings, assembly instructions, ship weight)
Units shown: inch. Switch units to: mm
| Part No. | Overall Dimensions | Rack | VESA | |
|---|---|---|---|---|
| Height | Width | Units | Pattern | |
| RMMB193UBK3 | 5.25 | 19.00 | 3U | MIS-D |
Attributes
| Additional Downloads |
|---|
| Specification Sheet |
| Part Attributes | |
|---|---|
| Part Number | RMMB193UBK3 |
| Series | Rack Mount Monitor Blank (RMMB Series) |
| Short Description | 3U VESA MIS-D MONITOR MOUNT |
| Shipping Weight | 3 lbs (1.36 kg) |
| UNSPSC | 43201618 |
| UPC | 623980698847 |
| REACH Compliant | Yes (more info...) |
| RoHS Compliant | Yes (more info...) |
