Description
Features:
- Constructed of 6063 aluminum.
- EIA-310-E compliant 12-24 threaded mounting rails on both sides of the rails.
- Screen-printed numbered rail markings.
- Side ganging and accessory mounting hole provisions.
- Self-squaring design ships un-assembled (some assembly required).
- Includes a 30-pack of 12-24 mounting hardware.
- Available in either an anodized black or anodized natural finish.
- 1,500 lbs (680 kg) load rating when weight is distributed centrally and the rack is anchored to the floor.
- RoHS Compliant.
Part of the Rack Basics® line of economy rack solutions
Convert this product into a four-post rack when you purchase two (2) racks as well as our new Four Post Rack Kit (FPRK). Click here to learn more.
Accessories
-
Server Rack Finger Vertical Cable Manager
-
Server Rack Cable Manager
-
Vertical Cable Manager Extensions
-
Horizontal Ring Cable Manager
-
Horizontal Finger Cable Manager
-
Rack Panels
-
Universal Rack Shelf
-
Adjustable Rack Shelf
-
Variable-Depth Rack Shelf
-
Centered Rack Shelf
-
Keyboard & Equipment Rack Shelf
-
Universal Four Post Rack Kit
-
Server/UPS Support Bracket
-
2-Post Rack Low Profile Dolly
-
Rack and Cabinet Stem Casters
-
Open Frame Rack and Rack Cabinet Joining Kit
-
Rack Isolation Kit
-
Bonding and Grounding
-
12-24 Mounting Hardware
-
We Manufacture PDUs and Outlet Strips
Attributes
| Additional Downloads |
|---|
| Specification Sheet |
| Part Attributes | |
|---|---|
| Part Number | RB-2PA1945BK |
| Series | 2-Post Aluminum Open Frame Rack (RB-2PA Series) |
| Short Description | 45U 19IN 12-24 2-POST RACK |
| Size H x W x D |
83.9 in x 20.25 in x 15 in (2,131 mm x 514 mm x 381 mm) |
| Shipping Weight | 28 lbs (12.70 kg) |
| UNSPSC | 43223308 |
| UPC | 623980412030 |
| REACH Compliant | Yes (more info...) |
| RoHS Compliant | Yes (more info...) |
| Rack Units | 45 |
| Rack Type | Open Frame Rack |
| Paint Color | RAL9005 Black |
| Rail Type | Tapped 12-24 |
