Description
Features
- Constructed in 14-gauge steel.
- 19" mounting EIA tapped 10-32 mounting rails.
- Horizontal or vertical equipment mounting.
- Rear cable access for cable management.
- The VPB196UBK can be rack-mounted to provide vertical rack mounting for deep equipment such as a server. It also includes side cable access.
- Finished in RAL9005 black powder paint. Complies with the Greenguard guidelines for indoor air quality.
- Includes a package of ten (10) SCREW1032-10 screws.
- 135 lbs (61 kg) static load rating.
- TAA-compliant for federal GSA schedule purchases within the USA.
- RoHS Compliant.
- Manufactured in North America within an ISO 9001:2015 certified facility.
The VPB Series Vertical Mounting Wall Rack is a robust solution for organizing telecommunications equipment while maximizing floor space. Constructed from durable 14-gauge steel, this versatile rack offers flexibility with horizontal or vertical mounting options. It features easy cable management and a sleek black powder coat finish for a modern look. Ideal for IT rooms, offices, and home networking setups, the VPB supports various configurations, ensuring efficient space utilization and superior organization for your equipment.
Gallery
Accessories
-
Universal Rack Shelf
-
Hinged Clear Security Cover
-
Mounting Screw and Clip Nut Combo-Pack
-
We Manufacture PDUs and Outlet Strips
-
Ground Stud Kit
Attributes
| Additional Downloads |
|---|
| Specification Sheet |
| Part Attributes | |
|---|---|
| Part Number | VPB196UBK |
| Series | Vertical Mounting Wall Rack (VPB Series) |
| Short Description | 6U VERTICAL WALL RACK |
| Long Description | Heavy Duty Vertical Wall Bracket - 6U x 11.19" dp |
| Size H x W x D |
11.19 in x 19.19 in x 11.19 in (284 mm x 487 mm x 284 mm) |
| Shipping Weight | 6 lbs (2.72 kg) |
| UNSPSC | 43223308 |
| UPC | 623980895598 |
| REACH Compliant | Yes (more info...) |
| RoHS Compliant | Yes (more info...) |
| Rack Units | 6 |
| Rack Type | Open Wall Rack |
| Paint Color | RAL9005 Black |
| Rail Type | Tapped 10-32 |
