Description
The LC/UPC to SC/UPC Hybrid Simplex OS2 Single Mode Fiber Optic Adapter is a high-performance solution for seamlessly connecting different fiber connector types. Specifically designed to bridge the gap between 1.25mm LC and 2.5mm SC configurations, this hybrid coupler ensures precision alignment and minimal signal loss in mission-critical networks.
Key Features
- Hybrid Connectivity: Bridges LC/UPC and SC/UPC interfaces, eliminating the need for expensive hybrid cable assemblies.
- High Precision Alignment: Equipped with a premium Zirconia Ceramic Sleeve for low insertion loss (≤0.2dB typical) and high return loss.
- OS2 Single Mode Optimized: Engineered for 9/125µm OS2 single mode applications, supporting high-speed data transmission over long distances.
- Durable Construction: Features a lightweight, UL 94V-0 rated plastic housing that is resistant to environmental wear.
- Integrated Flange: Built-in flange provides stable and secure mounting for standard fiber patch panels, wall plates, and enclosures.
- Tool-less Installation: Simple snap-in design with protective dust caps included to keep the internal ceramic sleeve clean and clear of debris.
Applications
This adapter is ideal for use in 10G/40G/100G Ethernet environments, including:
- Data Centers and Enterprise Networking
- Telecommunications and FTTH (Fiber to the Home)
- CATV, LAN, WAN, and MAN Applications
- Testing Equipment and Fiber Patch Panels
Technical Specifications
| Connector Type | LC/UPC Female to SC/UPC Female |
| Fiber Mode | Single Mode OS2 9/125µm |
| Body Style | Simplex |
| Insertion Loss | ≤ 0.2dB |
| Sleeve Material | Zirconia Ceramic |
| Flammability Rate | UL 94V-0 |
| Operating Temp | -25°C to +70°C |
