Description
The Optix 3X 900um ST Mechanical Connector is a high-performance, field-installable solution designed for fast and consistent fiber terminations. This ST connector features a simple two-piece design that allows for reliable field installation in less than two minutes without the need for specialized connector holders.
Key Features:
- Reusable Technology: Patent-pending design provides up to three opportunities to re-splice or reuse the connector, eliminating the "one-and-done" waste of traditional mechanical connectors.
- Premium Fiber: Manufactured with genuine Corning fiber for superior signal integrity and long-term network reliability.
- Universal Compatibility: Works seamlessly with all major fusion splicer brands using standard sheath clamps or fiber holders.
- Durable Build: Features flame-retardant housings and a robust silicon boot for excellent strain relief and protection in tight enclosures.
- VFL Verification: Integrated window allows for real-time verification using a Visual Fault Locator (VFL) to ensure a perfect connection.
Specifications:
- Connector Type: ST (Multimode)
- Fiber Grade: OM1 62.5/125µm
- Polish Type: PC
- Cable Compatibility: 900 micron and 250 micron coated fiber
- Color: Beige (Housing & Boot)
- Insertion Loss: MM Average: 0.10 dB (Max: 0.3 dB)
- Operating Temperature: -40°C to +75°C
- Compliance: Fully compliant with TIA/EIA 604-3 standards
